DTF factory TODOjet low costs 300mm dtf pinter with shaker with XP600 printhead

No stroke, full hollow, high productivity, no plate making, no engraving, no waste discharge
The shaking fine powder is very clean and fast. After heat transfer, the clothes pattern feels comfortable and firm, and the tensile strength is strong and does not crack.

When it comes to personalized custom clothing printing, the DTF-T30 Printer has emerged as the top choice for startups and established businesses alike. In this article, we will explore the reasons why the DTF-T30 Printer is preferred by many and how it meets the demands of the industry. Read on to discover the key factors that set the DTF-T30 Printer apart.

TODOjet is a professional DTF printer in China. We attend many exhibitions in printing filed. Now we have the DTF printing machine line of 30cm, 60cm and 120cm for diffrent customer use. The DTF printer can print on various fabric such as cotton, canvas, polyester, blends, nylon etc which solves the restriction of DTG printer.

New digital printing process-DTF
DTF is directly printed to film, and the digital printing process has significant advantages. One of the biggest benefits is that it can be used to print on white or dark T-shirts without pre-processing. This process supports printing on various fabrics with or without white ink.
Product name:Digital Heat transfer PET Film T-Shirt Printer
Print head number:1/2 pcs XP600
Media Type:PET Film (Premium Quality)
RIP software:Maintop/Photoprint
Printing Speed:3-10 sqm/h
Printing Color: CMYK+W
Max Printing Width :A3 size/ 310mm

Model: DTF-C30
Printhead: 3 × Epson I1600
Printing Color: CMYK + CMYK + W
Printing Speed:

6PASS: 12m²/h
8PASS: 8m²/h
Printing Size: 300mm
RIP Software Compatibility: Riin, Flexiprint, Cadlink, Maintop
Take-Up Method: Fully automatic induction take-up
Heating Method: Independent heating for front and back
Ink Supply System: Automatic ink supply with white ink circulation and stirring
Power Supply: 110V/220V, 50-60HZ, 400W/1500W
Work Environment: Temperature: 18°C-26°C; Humidity: 35%-70%
Dimensions:
Printer: 1168 × 884 × 1218mm
Powder Shaker: 640 × 932 × 577mm

TODOJet direct film printer creat a new solution about garment printing,with both breathable vents and fluorecent colors printing function. Breathable vents can make sure the T-shirt wearing more comfortable,and fluorecent orange and green can make your T-shirt looks more special.
More details about our DTF printer,kindly contact with our team.

White ink timing stirring function, every 30 minutes, the machine will automatically stir the white ink to prevent precipitation (automatic, no manual operation required)

1.Up and down cap station
Better seal performance for the printhead
2.Temperature control
Front and back, 2 stage heating
3.Hiwin guide rail
Printing more stable and quiet
4.Good working performance
Fluorescent orange and green are support

1.Any fabric textile cloth material,any color,any part printing.
2.Best solution for print on demand,custom garment printing.
3. Convenient, high efficiency and low cost: One-stop hollow printing, no cutting plotter, laminating machine, hollow machine,no watse
discharge, time and labor saving.
4.Good effect: the pattern is soft to the touch,washable and stretchable, and the wet and dry fastness reaches level 4.
5. A wide range of applicable materials: printable materials include cotton fabrics, high-elastic fabrics, nylon fabrics, chemical fiber fabric,sswimwear,denim,PVC,EVA,etc.
6.The DTF printer used eco pigment ink and pigment ink which are much economic than DTG ink. It accept all type facbric heating transfer printing with vivid design.

DTF Advantages
Cost-effective: can save up to 50% white ink; supplies are also significantly more affordable.Easy operation: DTF allows you to apply the artwork on difficult/awkward parts of the garment or fabric with ease. High stretch-ability and soft hand feel.

Screen printing, also called silk screen printing or silk screen printing, is a printing method in which a printing plate is supported on a finely woven silk screen, and the screen is taut and fixed on the screen frame.The material to be printed is placed under the screen frame, and the liquid ink is squeezed downward by a “squeegee”, passing down through the porous material.
Then, the image and text part of the ink-permeable printing plate is transferred to the material to be printed.
Screen printing differs from other printing forms in that it uses pigment inks, which form a thick layer of ink on the paper surface, resulting in bright and vivid colors.

Lightfastness of transfer clothes: the color will not fade under direct sunlight.

1) Simple structure in linear type, easy in installation and maintation.
2) Adopting advanced high quality components in pneumatic parts, electric parts and operation parts.
3) Running in a high automatization and intellectualization, no pollution.
4) 3D printing effect, real, realistic, delicate.

1. High-speed printing 12m²/hour in high-speed mode and 10m²/hour in high-speed mode, the printing effect of high-speed mode exceeds that of high-definition machines on the market.
2. The heat press machine has constant tension feeding and damping feeding, which overcomes the influence of tension and supports large rolls to reject arched paper.
3.Color ink and white ink double-circulation ink supply, PLC control ink supply system, independent adjustment of pressure and flow rate, to overcome the influence of ink failure and temperature.

1. Use the printing software of the white ink heat press machine to print the picture. This kind of white ink heat transfer should be equipped with at least two nozzles, one nozzle for white ink and one nozzle for color ink. There are also four nozzles, two for white ink and two for color ink. The speed is fast, but the accuracy will be slightly reduced. During the printing process, the printer first prints the color map on the special release printing film, and then prints a layer of white ink on the color map.

Application range:
Personalized pattern T-shirts, finished clothes, sweaters, clothing sets, luggage pieces, leather printing, jeans, team uniforms, work clothes, class uniforms, group clothing… TODOjet white ink heat transfer printer belongs to the more upgraded process of digital offset heat transfer processing , making T-shirt clothes printing more convenient and lower threshold.

When printing directly to textiles, your options are limited to pure cotton. DTF printers gives you more flexibility as you can print on a variety of fabrics including cotton, polyester, rayon, nylon, silk, leather and more.

1. Use software draw the pictures , and then use the printer to print the pattern on the PET machine
2.Sprinkle an appropriate amount of hot melt poweron the printed PET film and shake off the excess hot melt power
3. Put the PET film on the heat transfer machine and back for 5-7 minutes ,until the hot melt powder melts , take out the PET film
4. Lay the T shirt flat on the heat transfer amchine and stick the sidesprinkled with hot melt powder on the T shirt for pattern

Q: What does after-sales service include?
A: The company provides technical support for a long time, and provides “lifelong technical and training services” for each customer to help customers solve various problems encountered in the production process in real time, and feedback the technicians to propose solutions at the first time. Try to ensure that your production work is not delayed.

DTF Printer and DTF Powder Oven (A3 size) widely used to customize the T-shirt, hoodie, scokes, shoes, bags, etc
TODOjet mainly engaged in the sales of digital printing equipment, our company’s products are sublimation printer/white ink hot stamping powder shake machine/ sublimation heat transfer machine/thermal transfer paper/ transfer ink/white ink hot stamping supplies.

PET detached film is a material commonly used in thermal transfer printing, the substrate is PET, after being coated with silicone oil, so it is also called silicone oil film.There are hot peel and cool peel . After anti-static and anti-scratch treatment, the product has a very good adsorption and fit.

DTF water-based white ink printing film is a new type of printing film, which has many advantages that the old printing film did not have. White ink printing film uses water-based ink, which has better environmental protection. Compared with the traditional weak flux printing film, it has better air permeability and hand feeling. And it has better washability and durability. Solved the problem of small cutouts. It has the characteristics of full color and so on.

24″ 60cm A1 DTF Printer TEXTEK A602 Direct to Film 2-in-1 Printer Power Shaker Wholesale is a powerhorse for fast and mass sticker transfer production in 2024.

TODOjet DTF printer offer Epson XP600/F1080 and i3200-A1 printhead for option, this A3 Pro DTF heat transfer printer usually together with a powder shaker machine, and the DTF printer with rewinding device support roll to roll printing, improve the product efficiency.

DTF means direct to film printing,its an alternative printing process to DTG printer.It is generally known that DTG is direct to garment printer,which is suitable for cotton fabrics printing,such as cotton T-shirt, POLO shirt printing. And DTF printer is suitable for all non-fabrics printing,such as polyester, hat printing,shoes printing,canvas printing.

Product features of heat transfer machine: The bottom plate is equipped with high temperature resistant foaming silicone, which can withstand temperature up to 350°C.

No need to stroke, no need to empty, no need to engrave, one-man operation, one piece of printing, environmental protection, no waste, no limit to fabrics, soft and washable, suitable for personalized heat transfer customization and batch processing of various fabrics Automated manufacturing.

DTF ink storage environment:
DTF ink needs to be placed in a cool place, must not be placed in direct sunlight, not exposed to the sun, or placed in a place where the temperature is too high or too low, otherwise it will cause the unopened ink to deteriorate. In addition, the shelf life of DTF ink is 12 months when stored in a standard environment.

Our DTF machine:The printing speed is much faster than the modified machine. We researched and developed independently, so the machine runs stably and the failure rate is low. Equipped with white ink stirring, it is not easy to block the nozzle.

TODOjet A3 DTF printer is such a magic machine! Why? Because it can print pretty much all kinds of fabric materials like cotton, silk, nylon, canvas, leather etc. It is small-size, cost-effective, high quality and high efficient so many customers start own business with this magic machine.
