Factory direct sales E30 DTF printer, suitable for all kinds of customized business, exquisite color reproduction, white ink circulation system

1. This equipment is a new generation of digital revolution, pioneering and leading a new digital heat transfer process.
2. This equipment makes up for the shortcomings of the existing process. It only needs printing + pressing, and the printing can be done in two steps.

New digital printing process-DTF
DTF is directly printed to film, and the digital printing process has significant advantages. One of the biggest benefits is that it can be used to print on white or dark T-shirts without pre-processing. This process supports printing on various fabrics with or without white ink.
Product name:Digital Heat transfer PET Film T-Shirt Printer
Print head number:1/2 pcs XP600
Media Type:PET Film (Premium Quality)
RIP software:Maintop/Photoprint
Printing Speed:3-10 sqm/h
Printing Color: CMYK+W
Max Printing Width :A3 size/ 310mm

All of our printers can print, and design different patterns according to different products. After printing, the original ordinary products can appear more high-end, more vivid and more attractive. DTF printing can give your product new life and enhance the value of your product.

Auto shaking and Curing function
Mesh belt conveyor
Control pannel of Shaking Machine
The powder machine desighed with seperate body, which is easy to entrance any shopping door, suitable for the customer whose space is limit.

A3 SIZE WHITE INKPET FILM PRINTER& AUTOMATIC DRYING AND SHAKINGPOWDER INTEGRATED MACHINE
NEW RESOLUTION FOR UNIVERSAL PRINT
TRANSFER PRINTING ALL KINDS OF FABRICS
FREE TEACHING +LIFE-LONG AFTER SERVICE
REPLACE PLOTTER CUTTER & HTV

A3 Dtf Printer occupies a small area and is easy to operate.One person can operate multiple machines.There is no need to engrave and discharge waste and film, which effectively improves production efficiency, does not limit patterns, and is naturally hollowed out and thinner and breathable.High cost performance, no need for high investment in equipment and space greatly reducing investment costs.

DTF ink storage environment:
DTF ink needs to be placed in a cool place, must not be placed in direct sunlight, not exposed to the sun, or placed in a place where the temperature is too high or too low, otherwise it will cause the unopened ink to deteriorate. In addition, the shelf life of DTF ink is 12 months when stored in a standard environment.

AGP S30 A3 UV DTF Printer Wholesale Price Hot Sale Epson l1600 Sticker Transfer Printing is a powerful direc to film printer. Boosts a ultravilot LED curing system, it will print fabulous sticker transfers for you.

Improve production efficiency
The TK1600 has an automatic paper feeding and recycling system, which reduces manual intervention through automated operation, significantly improves production efficiency, and helps you save time and costs.

What is the reason for the light color of the image transferred to the T-shirt with thermal transfer ink:The relationship between the temperature of the transfer and the time is a matter of operating skills.

4 reasons to choose AGP
According to customer needs/provide solutions/support customization
Professional products, professional technical team, and professional services

Personlig udskrivning: meget velegnet til forskellige personlige farveudskrivningstjenester såsom T-shirts, puder (sæt), indkøbsposer, forklæder, handsker, bomuld strømper, lommetørklæder osv. Det har stærk stabilitet og løser mange mangler ved de eksisterende flatbed-printere. Eftersalgsservice garanti: professionel F & U, produktion og eftersalgsservice. Egnet til udskrivning på ethvert materiale og materiale.

1.Versatility on materials : DTF can be applied on a wide range of materials including cotton, nylon, treated leather, polyester, 50/50 blends and more (light and dark fabrics).
2.Cost-effective: can save up to 50% white ink; supplies are also significantly more affordable.
3.Wash ability: has been proven through testing to be equal to if not better than traditional direct-to-garment (DTG) printing.

Product name:TODOjet A3 DTF Pro Printer
Print color:CMYK+Fluorescent Orange + Fluorescent Green + White
RIP software:Maintop/ Photoprint
Language:Multi Language Include Enlish
Print speed:4.5-5 sqm/h
Print head:XP600
Application:Cloth
Video outgoing-inspection:Provided
Warranty of core components:1 Year
Core Components:Motor, Pump, Gear

1.Up and down cap station,Better seal performance for the printhead
2.Temperature control,Front and back, 2 stage heating
3.Hiwin guide rail,Printing more stable and quiet
4.Good working performance,Fluorescent orange and green are support

Sublimation Printing: Originally, this involved printing patterns onto special transfer paper, followed by cutting using an edge finding plotter, manual hollowing out, and finally transferring the design onto fabric using a heat press machine. However, sublimation is known for its low efficiency and less-than-ideal tactile feel.

In the clothing industry, white ink heat transfer printers are regarded as very competitive weapons. Through AGP DTF printers, designers can better display clothing printing creativity and achieve better printing effects. Clothing manufacturers can also quickly launch new clothing products with white ink heat transfer technology, catch up with the trend and meet the needs of the clothing market.

Garment printers can print on various rolls or sheets of materials, such as: thermal transfer film, film, self-adhesive, PU film, etc. At present, the most popular application is in the clothing industry.

We all know that the most valuable part of a printer is the print head. Todojet white ink printers are equipped with a print head anti-collision device. When the print head touches a hard object, it will automatically cut off the power and stop printing, and the platform vacuum suction + paper press prevents the paper from being warped. Scrape the nozzle to effectively protect the nozzle and prolong the life of the nozzle.

Model: DTF-C30
Printhead: 3 × Epson I1600
Printing Color: CMYK + CMYK + W
Printing Speed:

6PASS: 12m²/h
8PASS: 8m²/h
Printing Size: 300mm
RIP Software Compatibility: Riin, Flexiprint, Cadlink, Maintop
Take-Up Method: Fully automatic induction take-up
Heating Method: Independent heating for front and back
Ink Supply System: Automatic ink supply with white ink circulation and stirring
Power Supply: 110V/220V, 50-60HZ, 400W/1500W
Work Environment: Temperature: 18°C-26°C; Humidity: 35%-70%
Dimensions:
Printer: 1168 × 884 × 1218mm
Powder Shaker: 640 × 932 × 577mm

Using the shake powder could consider these procedures.
Dusting.
1.What is the powder sprinkled with?Hot melt powder, when the heat is sticky, after the formation of glue coating;
2.Why?Stick hot melt stick to the dry ink to help eventually form the coating;
3.How to sprinkle, sprinkle how fast?Can adjust the knob on the shake powder machine;
4.How much?The powder is about 2-3cm thick to stop sprinkling the powder.
Shaking.
1.Why shake powder?Shake off the excess powder on the ink and film adhesion, so that the powder is thin and evenly attached to the ink.
2.Shake powder speed.Depending on the situation, the knob on the condition machine, about 2-3 gear ok.
Drying.

1.Why drying?Melt the hot melt powder to create a reprint pattern coating;.
2.How long will it bake?Undefinite, depending on the specific situation, mainly to ensure that the pattern feels no powder, hot melt powder all melted into coating.
3.Temperature? 90-130 ° C is ok.

ذاتي ڪسٽمائيز ماڊل ڊسپلي، ذاتي ٽي شرٽ، ٽيم يونيفارم، ڪم يونيفارم، ڪلاس يونيفارم، جرسي، سامان، وغيره.

TODOjet white ink heat press machine heat transfer film connection printer tutorial: 1. The mesh belt absorption button is turned on. 2. The mesh belt synchronous receiving button is turned off. 3. The back paper crying button is turned on. Quick 5. After the take-up reel is connected, the mesh belt suction can be closed

All-in-one machine for heat transfer and powder shaking:
1.Convenient, high efficiency and low cost: One-stop hollow printing, no cutting plotter, laminating machine, hollow machine, no waste discharge, time and labor-saving.
2. Good effect: the pattern is soft to the touch, washable and stretchable, and the wet and dry fastness reaches level 4-5.

TODOjet offer you a brand new solution of digital PET transfer film color printing
-Saving Manpower
-No Engraving
-Widely Usage
-User Friendly
-No Waste Discharging

Uma nova solução para transferência de calor de tinta branca, solução de impressão personalizada preferida da loja de impressão, Bai Caitong sai com uma solução de transferência de calor de tinta ecologicamente correta, que é um processo de aplicação de transferência de calor de vestuário subversivo.

Whether it is small-volume proofing or mass production, as long as there is a picture, the finished product can be printed directly, which is convenient and fast, saves time and effort, and saves time and labor costs.

DTF Printing offers a print service like no other! We Print Create awesome T-shirts, Hoodies, Tote bags, etc. We use high-end production DTF printers for creating our DTF transfers. We have A3 DTF Printer and A1 DTF Printer. These printers give us the highest quality prints and able us to print at very high speeds, therefore, offering a fast and efficient turnaround.Helping You Create Perfect Designs whether they are your own or you are branding.

Tige de vis et rail de guidage importés: L’ensemble de la tige de vis de la machine et du rail de guidage adopte la tige de vis de meulage en argent importée de Taiwan et le rail de guidage silencieux. Le bruit généré pendant le processus d’impression est considérablement réduit et l’erreur est plus petite. Le curseur et le rail de guidage sont parfaitement intégrés. L’opération de production est plus stable en utilisation.

Max media: 30cm width
Heating size: 40cm
Voltage: 220V/5A
Power: 3.4kw
Take up function: Automatic inductive
Machine size: 850*650*600mm
Packing size/Weight: 790*610*710mm/50kg
